Description
Product Features
- High SPL and sensitivity
- One 8″ high power low frequency driver
- One 1″ PEI diaphragm compression driver
- Passive configuration
- 140º x 140º wide angle coverage pattern
- Computer aided design to optimise frequency and phase response
- Multi purpose cabinet design for FOH or monitor use
- Use as a main system with or without subwoofer augmentation
- Suitable for speech (meeting and conference rooms), background music (bars and other public spaces)
- Flexible and easy-to install configurations (wall, ceiling, under balcony)
- U bracket included
- Combine with any EB or EJ Series high power subwoofer for extended low frequency, high quality music reproduction
Cabinet Dimensions
Technical Specifications
| Transducers: | Low Frequency: 08LB050-L High Frequency:25ED25-8+25H156 |
|---|---|
| Frequency Response (-3dB): | 85Hz-19kHz |
| Sensitivity (1W/1m): | 93dB |
| Crossover Frequency: | 2.5kHz |
| Dispersion (H x V): | 140º x 140º |
| Rated Power (RMS): | 100W |
| Rated Impedance: | 8ohm |
| Input Connectors: | NL4 x 2 |
| Net Weight: | 8.0kg |
| Gross Weight: | 19.0kg |
| Dimensions (W x D x H): | 258 x 247 x 408mm |
| Packaging Dimensions 2pcs/pack: (W x D x H) |
630 x 350 x 520mm |
| Warranty: | 3 Years |
