Description
Product Features
- Rear Loaded Transmission Line subwoofer
- Down to 28Hz at -6dB and still 104dB/1W/1m Efficiency
- Real 3000W RMS power capacity
- Premium 18” LF drivers with massive ±15mm linear Xmax
- Triple forced cooling system for low power compression
- Heavy braced cabinet for vibration free dynamic response
- Touring grade Rubberised black PolyUrea finish
- Cardio Subwoofer Array Ready
Applications
SU218TL subwoofer is suitable for heavy bass reinforcement for main PA systems, touring or permanent installations for small to large stages, indoor or outdoor live performances.
Suitable in spaces like:
– FoH
– Multi-functional room
– Auditorium and Theatre
– Pub
– Bar
– Night club
– Commercial announcements
Cabinet Specifications
| Transducers: | Low Frequency: 18″ CELTO Acoustique Ferrite magnet, 4” ultra long stroke In / Out Voice coil |
|---|---|
| Frequency Response (-3dB): | 26~900Hz |
| Sensitivity (1W/1m): | 104dB/W/m |
| Maximum SPL (calculated): | 131dB continuous / 134dB Program |
| Crossover Frequency: | No, active mode only (CLM48 DSP) |
| Dispersion (H x V): | Omni in useable band |
| Rated Power (RMS): | 3000W RMS / 6000W Program |
| Rated Impedance: | 4ohm LF, |
| Speaker Connectors | 3x NEUTRIK Speakon® NL4MP (1+/1- Input) (1 in Front, 2 at the Back) |
| Flying Hardware | No, stack ground use only |
| Pole Mount | 20mm threaded pole mount |
| Floor Monitor | No |
| Net Weight: | 111kg |
| Gross Weight: | 123kg |
| Dimensions (W x D x H): | 1246x580x728 mm |
| Packaging Dimensions 1pcs/pack: (W x D x H) |
1400x700x850 mm |
| Warranty: | 3 Years |
