iFix17S

$1,499.00 Excl. GST

iFix17S subwoofer is suitable for bass reinforcement for main PA systems, indoor and outdoor. Suitable for: Trendy night clubs, Multi-functional rooms, Pub and restaurants, Auditorium and Theatre Background music.

Out of stock

Description

Real 700W RMS power capacity (8 hours pink noise) Long excursion 17” LF drivers with ±8.5mm linear excursion. Trimmed chassis for 18” performance in 15” size cabinet. Genuine European dia-cast Celto custom driver offers Incredible deep tones from ultra compact cabinet Heavy braced cabinet for vibration free dynamic response.

The whole range is available as standard in white, black or natural wood finish*. Also all RAL colors are available on demand to ensure the best possible integration to the decoration. *(RAL and natural finish extra)

Applications

iFix17S subwoofer is suitable for bass reinforcement for main PA systems, indoor and outdoor. Suitable for: Trendy night clubs, Multi-functional rooms, Pub and restaurants, Auditorium and Theatre Background music.

iFix17S SubWoofer Features

  • High output SPL and sensitivity
  • One 17″ high powered low frequency driver
  • 3.5″ Voice Coil
  • Omnidirectional
  • Computer aided design to optimise frequency and phase response
  • Cabinet design for FOH use
  • Powder coated grill with foam backing
  • Birch Plywood wth tongue and groove construction
  • 6 x M8 Flying points
  • Durable Polyurethane textured base paint
  • Portable system or for permanent installation

Cabinet Dimensions

ifix17s dimention

Technical Specifications

Transducers:  Low Frequency 17.5″
Frequency Response (-3dB): 38Hz-1200Hz
Sensitivity (1W/1m): 99dB
Maximum SPL (calculated):  127dB RMS / 133dB Peak
Crossover Frequency: n/a
Dispersion (H x V): Omnidirectional
Rated Power (RMS): 700W (AES Standard)
Rated Impedance: 8ohm
Speaker Connectors: Terminal Posts
Net Weight: 29Kg
Gross Weight: 34Kg
Dimensions (W x D x H): 482 x 596 x 600mm
Packaging Dimensions 1pcs/pack:
(W x D x H)
550 x 650 x 680mm
Warranty: 3 Years
