Description
DL351 is Modular Stage Box with 8 Card Slots and up to 64 Inputs and 64 Outputs.
Product Features
- Modular stage box accepts 8 DL4 series I/O cards
- Up to 64 audio inputs and 64 audio outputs
- 24 bit audio operation with 96 kHz sample rate
- Remote operation up to 100 m via CAT5/5e cable
- All settings programmable from front panel controls or console
- PSU status indicator LEDs and configuration LCD display on front panel
- 4 AES50 network ports for redundant connections
- Two GPIO 25-pin D-type opto-isolated connectors for external device control
- MIDI In, Out and Thru connectors
- Features Neutrik etherCON* AES50 network ports
- Rugged 7U rackmount chassis for durability in portable applications
- Dual redundant auto-ranging universal switch-mode power supplies
- 10-Year Warranty Program*
- Designed and engineered in the U.K.
Technical Specifications
| Dimensions | 7U x 416 mm (16.4″) deep |
| Net weight | 16.9 kg (37.2 lbs) |
| Power requirements | 100 to 240 VAC, 50 to 60 Hz |
| Operating temperature range | +5°C to +40°C |
| Storage temperature range | -20°C to +60°C |
Inputs and Outputs
| MIDI and GPIO | |
| Digital system inputs and outputs |
