Description
Product Features
- Medium scale sound reinforcement
- Two 12″ Neodymium low frequency drivers
- Symmetrical horizontal dispersion
- Splay angle rangle 0º to 10º
- Impact and weather resistant polyurethane finished birch plywood cabinet construction
- Optional TLF-101 Flying Frame
- Multi-function subwoofer which arrays with TLA-101 line array
- Can also be used in a ground stack configuration
TLB-101 Cabinet Dimensions
Technical Specifications
| Transducers: | Low Frequency: 2×12″ Neodymium Drivers |
|---|---|
| Frequency Response (-3dB): | 35Hz-250Hz |
| Sensitivity (1W/1m): | 100dB |
| Rated Power (AES): | 800W |
| Rated Impedance: | 4ohm |
| Input Connectors: | NL4 x 2 |
| Net Weight: | 45.5kg |
| Gross Weight: | 49.5kg |
| Dimensions (W x D x H): | 388mm (15.3”) x 699mm (27.5”) x 800mm (31.5”) |
| Packaging Dimensions 1pcs/pack: (W x D x H) |
560mm (22.1”) x 815mm (22”) x 935mm (36.9”) |
| Warranty: | 3 Years |
