Description
Product Features
- Medium scale sound reinforcement
- Two 10″ Neodymium Kapton low frequency drivers
- Two (4″x1″) Neodymium Kapton compression drivers
- Bi-amp configuration
- 90º constant directivity horizontal dispersion pattern
- Symmetrical horizontal dispersion
- Splay angle range 0º to 5º in 0.5º steps
- Impact and weather resistant polyurethane finished plywood cabinet construction
- Optional TLF-101 Flying Frame
- Arrays with TLB-101 dual 12″ subwoofers for extended low frequency, high quality music reproduction
Cabinet Dimensions
Technical Specifications
| Transducers: | Low Frequency: 2×10″ Neodymium Kapton drivers High Frequency: 2x(4″x1″) Neodymium Kapton compression drivers |
|---|---|
| Frequency Response (-3dB): | L: 100Hz-4.0kHz; H: 1kHz-19kHz |
| Sensitivity (1W/1m): | L: 104dB; H: 110dB |
| Dispersion (H x V): | 120º x 30º |
| Rated Power (RMS): | L: 400W; H: 80W |
| Rated Impedance: | L: 8ohm; H: 8ohm |
| Input Connectors: | NL4 x 2 |
| Net Weight: | 22.5kg |
| Gross Weight: | 25.5kg |
| Dimensions (W x D x H): | 800 x 503 x 300mm |
| Packaging Dimensions 1pcs/pack: (W x D x H) |
890 x 585 x 390mm |
| Warranty: | 3 Years |
